Introduction
This article is an investigation of the aluminum profile protective film /tape application machine
You will read about:
The best partner for aluminum profile film application——Brightstar aluminum profile film applicator machine
Aluminum profiles, stainless steel profiles, and plastic steel profiles have smooth surfaces, which are easy to scratch due to friction during storage and transportation, reducing the value of the product.
So, everyone will choose to cover the surface of the profile with a layer of protective measures – film application.
The film is sticked to the surface of the aluminum profile to protect aluminum profile from damage during the processes such as moving, storage, transportation, processing, and installation.
After the aluminum profile is installed, it will be torn off by the installation engineering team, so that the surface of the aluminum profile will be as clean as new and have the proper decorative effect.
And the “key weapon” that completes the film-sticking process is the aluminum profile film applicator machine.
Appearance
aluminum profile film applicator machine can be said to be the hottest product of Brightstar Machinery.
The film applicator machine of Brightstar Machinery includes the main machine, infeed roller conveyor and outfeed roller conveyor.
The whole main machine includes groups of wear-resistant PU rubber rollers up to the different models.
According to the strength required for the whole film sticking process, the hardness settings of the wear-resistant PU rubber rollers at each position are also adjusted.
In this way, the film can be as close as possible to the profile without air bubbles.
The whole profile film sticking process is smooth, and the film sticking speed can be adjusted according to your own needs.
PS: The rubber rollers on the film applicator machine are consumables and need to be replaced according to their wear to achieve the best film application effect.
Machine parts
The film application machine of Brightstar machinery is definitely a powerful tool with a good appearance, and the machine configuration is not sloppy at all.
Siemens motor – continuous strong power
LG frequency conversion control – adjustable film speed
We pay attention to every detail of the film application machine in order to get good performance in the operation.
Conclusion:
The value of protective film in the aluminum industry is very small, and it is only an auxiliary material used by manufacturers.
However, if it is used improperly, it may damage the surface quality of the product, bring loss to the user, and affect the corporate image of the product manufacturer.
This is not a process that can be ignored.
A film-applicated aluminum profile without air bubbles is a direct display of corporate image and strength.
The profile film application experience requires a powerful film application machine to support it, Brightstar Aluminum Machinery can provide you with the solution for the packaging.
What kind of machine is needed for aluminum profile film application?
Aluminum profile film applicator machine for the packaging
What kind of machine do the aluminum profiles need to apply for film sticking?
What is the price of this film applicator machine?
Brightstar Aluminum Machinery offers automatic aluminum profiles film applicator machine for our customers, whose price is between 3,000.00 and 15,000.00 USD.
For the specific case, the price depends on the final determining technical parameters and their configuration.
Aluminum profile film applicator machine is suitable for aluminum extrusion profile protective film/tape sticking, which is what we usually call a film applicator machine.
It is widely used in aluminum profiles, plastic profiles, sheets, pipes, building materials, and steel materials.
Our typical customer is HongQI Aluminum Extruder, who purchased 3 sets of film applicator machines at one time.
Here are some pictures of aluminum profiles film applicator machine.
Aluminum profile film sticking machine
Aluminum profile automatic film application machine
Aluminum profile automatic film application machine
Stable and reliable performance, simple operation, and less maintenance, which is why HongQi Aluminum purchased 4 sets of film applicator machines at one time.
It can prove the high quality of the product from the appearance of our equipment, for our existing customers, they know our machine valuable and that is the reason that they repeat purchasing the machines from us.
In view of those who have not used our machine, the good performance of the equipment can only be verified in the future but based on QC processes and our machine testing prior to the delivery, we can fully see the value of Brightstar brand.
Let’s talk about the features of our aluminum profile film applicator machine:
First
The protective film can be cut automatically, with no need manual operation, only need one operator, and save labor cost.
Second
Aluminum profile can be automatically conveyed by the outfeed roller conveyor, reducing workers working strength and improving working efficiency.
Third
Fast speed, film application for aluminum extrusion can be 6-10 pieces each minute.
Fourth
The film’s cutting edge is smooth, without burrs.
Fifth
Computer-controlled film automatic cutting.
Sixth
The pressing rollers and positioning rollers will be adjusted automatically when changing the aluminum extrusion for film application.
Seventh
The control system uses a control program composed of PLC integrated circuits, infrared light measuring instruments and other accessories to automatically locate the material position and cut the film during the film sticking process.
Eighth
Safe operation, low noise, less maintenance and longer service life.
If you want to take a look at our aluminum profile film applicator machine, you can come to our company for a factory tour, Of course, you can also check our equipment running operation in our customers’ factories.
The details add up to create the whole!
We will do what we can, with what we have and where we are.
Protective effect of protective film on aluminum profile
During the transportation, storage, processing and assembly of aluminum profile, the surface of aluminum profile needs to be protected.
To prevent harmful gases, microbial corrosion, dust pollution, mechanical scratches, scratches, etc.,
Make the product surface retain the original higher smoothness, improve the yield of secondary processing,
In addition, it can also be used for temporary protection in electroplating, printing, coating, printing and dyeing, etc.
The most commonly used method for protecting the surface of materials is to apply a protective film on the surface of the protected material.
The value of protective film in the aluminum industry is very small, and it is only an auxiliary material used by manufacturers.
However, if it is used improperly or if a protective film that does not meet the requirements is used, the danger is that it will not only fail to protect,
On the contrary, it may damage the surface quality of the product, bring tangible material loss and intangible brand image loss to the user,
Thereby affecting the price position of the product manufacturer and the sales of goods.
The correct use of the protective film not only improves the appearance and quality of the product but also facilitates the processing of materials.
The aluminum profile application machine improves the utilization rate of materials, reduces the production cost of products, and can also improve the brand image of the enterprise.
What are the operating specifications of aluminum profile film application machine?
Aluminum profile film application machine is a machine used to apply film to the surface of aluminum profiles.
The purpose of the film is mainly to protect the surface of the aluminum profile from being scratched or stained with dirt, and it can also beautify the aluminum profile with company brand.
However, if it is not used properly, the aluminum profile film application machine may malfunction or the film will not work well.
Therefore, when operating the aluminum profile film application machine, certain operating specifications need to be followed.
1. Keep the machine clean and tidy
The use environment of the aluminum profile film application machine is relatively strict, and it is necessary to ensure that the environment is clean and tidy.
Therefore, the machine needs to be cleaned and wiped before use to ensure that the surface and interior of the machine are clean.
In addition, it is necessary to regularly clean and maintain the machine to prevent the machine from malfunctioning and affecting the use effect.
2. Operate the machine correctly
When operating the aluminum profile film applicator machine, it is necessary to correctly learn the use method and specifications of the machine.
Before use, should carefully read the instruction manual of the machine, and consult the manufacturer about relevant issues to ensure that the aluminum profile film applicator machine you use is operated correctly.
In addition, the following points need to be noted:
(1). Adjust the direction of the film paper: the glue side that is easy to tear is facing down, etc.;
(2). Keep the working area clean and tidy;
(3). Clean the surface with a dust collector before trimming the film paper before opening the roll;
(4). Adjust the guiding device to make the gap between the film and the roller even;
(5). The order of the film paper is separated according to the front and back of the backing paper and placed on the tension wheel and the lower clip of the guide rail, and the backing paper is slowly released. If the backing paper is stuck, it must be released and then adjusted.
3. Use the right material
In the process of sticking film, it is very important to choose the right film material.
It is necessary to choose materials with good quality, short storage time, and good quality pressure-sensitive adhesive, otherwise, the glue may be too thin and easy to break, etc.
In addition, for different surface treatments of aluminum profiles, different film materials need to be selected to ensure the effect and protection of the film.
4. Keep machine maintenance
The aluminum profile film application machine needs regular maintenance to ensure the service life and effect of machine.
Specifically, the following points can be done:
(1). Regularly check whether the safety device inside the machine is normal;
(2). Be careful when replacing the film;
(3). Keep the machine clean and tidy, and pay attention to maintenance at any time;
(4). Before use, check whether the film tape is tight or not, and whether there is any debris stuck on the cutter wheel, and adjust the voltage of the electrolytic capacitor and the actual required value.
In short, the correct operation of the aluminum profile film application machine is the key to ensuring the effect of the film application and the life of the machine.
Only by following the operating specifications, choosing suitable materials, and maintaining the machine can a good film-sticking effect be achieved.
Aluminum profile automatic film application machine safety regulations
Aluminum profile automatic film application machine is an automatic protective tape sticking equipment, which is suitable for many kinds of materials, such as aluminum profile, metal sheet, PVC, acrylic, glass, etc.
In the process of using the equipment, in order to ensure the safety of the operator and the stability of the equipment, a series of safety measures must be taken.
1.The equipment must comply with relevant safety standards.
Aluminum profile automatic film application machines must pass mandatory certification and testing to ensure that they meet national standards and necessary safety requirements.
The equipment must have anti-error and emergency shutdown functions to prevent operators from misoperation and accidents under unsafe conditions.
2. Operators must receive professional training and guidance to understand the safe operating procedures and emergency disposal methods of the equipment.
Before operating the equipment, the working status of the equipment must be checked to ensure that all functions are normal and will not cause danger to operators and equipment.
Choose safe and reliable wires and power plugs to ensure electrical safety.
Before operating the equipment, safety protective equipment should be properly worn,
Including gloves, glasses, protective shoes, etc., to avoid mechanical and electrical injuries from the equipment.
3.Equipment must strengthen on-site management
When the equipment is used, it should be operated in strict accordance with the safety operation rules to avoid violations.
The surroundings of the equipment should be kept dry and ventilated to prevent failures and accidents caused by environmental factors such as water and moisture.
During the operation of the equipment, the operator should maintain concentration to prevent accidents caused by distraction.
Safety warning belts must be set up behind and around the equipment to prevent non-operating personnel from entering or dangerous objects from falling and hurting people.
4. Equipment must be maintained and serviced frequently
Every day the equipment must be cleaned and inspected to ensure that every part is maintained.
The components of the equipment, such as motors and transmission mechanisms, must be lubricated regularly to ensure the smoothness, operation and safety of the equipment.
When some parts of the equipment fail, the operator must repair and repair the equipment immediately.
The maintenance, inspection and repair of equipment should be carried out in accordance with detailed operating procedures to ensure safety and effectiveness.
In short, the safety of aluminum profile automatic film application machine is very important.
Before operation, serious training and standardized operation must be carried out professionally, so as to ensure that the equipment will not cause safety accidents for any reason during use.
Only in this way can we ensure the normal operation of the equipment, improve production efficiency and provide customers with high-quality services.
How to set the accuracy of aluminum profile automatic film application machine?
Aluminum profile automatic film application machine is a kind of equipment used to automatically stick the protective film on the surface of aluminum profile.
Its main function is to protect the surface of aluminum profile from damage and improve the service life of the aluminum profile.
The use of automatic film application machine for aluminum profiles requires the accuracy and quality of the film to reach a certain standard, which requires fine settings during installation and commissioning.
The accuracy of the aluminum profile automatic film application machine is mainly reflected in the position, angle and length of the film.
The specific setting method is as follows:
1. Setting of film position:
When setting the position of the film, it is first necessary to determine the width and thickness of the aluminum profile, and then adjust it according to the width and thickness of the film.
Normally, the film should be tightly attached to the surface of the aluminum profile, and there should be no misalignment.
2. Setting of film sticking angle:
The angle of the film of the aluminum profile automatic film application machine should be consistent with the angle of the surface of the aluminum profile to avoid problems of skewed film and unequal corners.
When setting the angle of the film, it needs to be adjusted according to the shape and size of different profiles to ensure the accuracy and quality of the position of the film.
3. Setting of film length:
The length of the film application is one of the important factors affecting the accuracy of the film.
When setting the length of the film, it is necessary to calculate according to the length of the aluminum profile and the width of the film to ensure that the length of the film just covers the entire surface of the aluminum profile.
At the same time, it is also necessary to pay attention to the internal length of the film, so as to avoid the situation that the length of the film is insufficient or too long.
4. Setting of film sticking speed:
When setting the film sticking speed, it needs to be adjusted according to the quality and thickness of the film sticking.
Normally, the film sticking speed should be moderate, which can ensure the accuracy of film sticking without affecting production efficiency.
In order to ensure the accuracy and quality of the aluminum profile automatic film application machine, we also need to pay attention to the following points:
(1)Before setting up, clean the surface of the aluminum profile and make sure there is no foreign matter.
(2)When adjusting the position and angle of the film, it is necessary to use professional tools to avoid errors.
(3)In the process of sticking the film, check the position and quality of the film at any time, and adjust and deal with it in time.
(4) During the production process, it is necessary to regularly maintain and maintain the aluminum profile automatic film application machine to ensure its normal operation and the stability of the film quality.
The accuracy and quality of the aluminum profile automatic film application machine need to be finely set and debugged to ensure its accuracy and stability.
Only by ensuring the accuracy and quality stability of the equipment can we meet the production requirements, improve production efficiency and reduce production costs.
Precautions for operation of aluminum profile automatic film application machine
With the continuous advancement of science and technology, automated production has been widely used and promoted in industrial production.
Aluminum profile automatic film application machine is a kind of automatic production equipment, which can help manufacturers improve production efficiency, improve product quality and reduce production costs.
However, in the process of using the aluminum profile automatic film application machine, it is also necessary to pay attention to some operational details to avoid potential safety hazards and production quality problems.
1. Safe use of equipment
The aluminum profile automatic film application machine is a big mechanical equipment, and its use requires strict compliance with operating safety regulations.
Before the operation, a comprehensive inspection of the machine is required to ensure that the safety performance of the equipment can be performed normally.
The inspection content includes whether the power connection is normal, whether the parts are loose, whether the fan is normal, whether the wheels and bearings are flexible, etc.
During use, the machine needs to be maintained regularly to ensure the normal operation of each component.
If it is found that there are potential safety hazards in the equipment or the machine fails, it should be stopped in time for maintenance or replacement of parts.
2 Operator safety
When using the aluminum profile automatic film application machine, it is necessary to pay attention to the safety of the operator.
Before the operation, it is necessary to explain the equipment in detail, tell the operator how to use the equipment correctly and avoid problems caused by improper operation.
During operation, operators need to wear protective equipment such as work clothes and safety helmets to avoid accidents.
When the equipment is in operation, the operator must keep a certain distance.
3. Material quality and usage
The aluminum profile automatic film application machine needs to use film materials with good quality and appropriate specifications and select the appropriate film according to the requirements of the product.
During operation, it is necessary to accurately adjust film tension, speed, viscidity temperature and other parameters according to needs to ensure the consistency and aesthetics of the film sticking effect.
4. Equipment daily maintenance
During the use of the aluminum profile automatic film laminating machine, attention should be paid to the daily maintenance and maintenance of the equipment.
After running for a period of time, the equipment needs to be cleaned and maintained to maintain its stable operation.
In addition, regular inspection and maintenance of the equipment is required to ensure the reliability and stability of the equipment and prevent production accidents.
5. Fixed operating procedures and records
When using the aluminum profile automatic film application machine, it is necessary to establish working procedures and operation records.
From the start-up of the equipment to the end of production, it is necessary to fix the operation process to avoid operating errors or negligence.
At the same time, it is necessary to record the production process, record the parameter settings, quality control, equipment maintenance and other data of each production batch, so as to facilitate production management and quality inspector inspection.
When using the aluminum profile automatic film applicator machine, it is necessary to strictly abide by the operating procedures and safety standards, strengthen the maintenance and maintenance of the equipment, improve production efficiency and quality, and avoid unnecessary economic and personnel losses.
Common troubleshooting methods of aluminum profile film application machine
When aluminum profile film application machine get a breakdown in the operation, if you are not clear about the structure and principle of the machine, and you cannot correctly judge and analyze the technical failure, you should not blindly dismantle it.
Unable to accurately determine the location of the fault, and blindly dismantle the machine with the idea of “probably, almost”, the result is that not only the original fault has not been eliminated, but also new problems have emerged due to poor maintenance skills and craftsmanship.
Therefore, when the machine breaks down, it must be detected by testing equipment.
If there is no testing equipment, through the traditional fault judgment methods and means such as “asking, looking, checking, and testing”, combined with the structure and working principle of the machinery, the location of possible faults can be determined.
Common troubleshooting methods of aluminum profile film application machine
The machine does not start:
The input wire is blocked, the power wire is reversed, and the voltage is not enough.
The working vacuum does not come up:
The Air piping is blocked, the hand valve or solenoid valve is not closed, the vacuum pump motor belt is loose, and the vacuum gauge is damaged.
Film application unfulfillment:
Insufficient vacuum; air leakage; too thin film; the workpiece is pasted with other materials; the concave depth of the workpiece exceeds the lifting of the film; the film is not pulled up and the distance between the workpiece is too close.
The surface of the covered workpiece has creases and is not smooth or the corners cannot be covered:
The film is not straightened; the film quality is not good and the workpiece is not grinded and cleaned well.
Bubbles and solutions
The protective film is wrinkled or loose, and the protective film is uneven or curled.
Solution:
The protective film should be replaced and the tension adjusted.
There are dust impurities on the surface of the protective film.
Solution: It should be removed in time.
Film wrinkling and solutions
The protective film transfer roller is unbalanced
Solution: The transfer roller should be adjusted.
The two ends of the protective film are inconsistent or wavy.
Solution: The qualified protective film should be replaced.
What should I do if aluminum profile film application machine gets stuck?
Aluminum profile automatic film application machine is a common machine and equipment in aluminum industry, which is mainly used to apply protective film or tape on the surface of aluminum extrusion, to protect the surface of aluminum extrusion and make brand promotion.
However, when operating and maintaining such a machine, it is inevitable to encounter some problems, such as the machine suddenly gets stuck or stopping working.
In this case, what should we do?
Here are some of the more common solutions:
We need to determine the cause of the stuck.
Usually, the reason why the machine is stuck may be caused by the following situations:
The quality of the film is not good so the film is not easy to move from the bracket;
Dust and grease have accumulated on the bracket, which seriously affects the rotation of the film roller;
Wear and overload of the internal parts of the machine, resulting in improper work.
We need to take appropriate action to resolve the issue, as follows:
1. Check and replace the quality of the film
In the case of a machine stuck, it is first necessary to check the quality of the film used, whether the thickness and texture of the film and other characteristics meet the requirements.
If the film quality is found to be poor, the film should be replaced in time.
2. Clean the bracket
Accumulated dust and grease on the brackets can be one of the main causes of stuck machines.
Therefore, before the next round of tape, the bracket should be cleaned in time to ensure that the film can slide smoothly.
3. Check the working status of the machine
If the above two solutions cannot solve the problem, then the problem may be caused by wear or overload of the internal parts of the machine.
In this case, the work of the machine should be suspended first, and a comprehensive inspection and cleaning should be carried out.
If some parts are found to be severely worn, they should be replaced in time;
If the machine is overloaded, the parameters should be adjusted or the working speed should be reduced.
4. Repair machine
If none of the above three methods can solve the problem, the machine may be facing a serious failure.
In this case, you should contact the manufacturer or technical engineers as soon as possible in order to obtain better technical support and assistance.
In short, when using the automatic film application machine, if the machine suddenly gets stuck, we should first determine the cause of the stuck and take appropriate measures to solve the problem.
If it cannot be solved, we should contact the manufacturer or engineers in time to obtain better technical support and assistance.
The necessity of applying protective film on aluminum profiles
Protective film is one kind of film material with a surface protection function, and it is also one of the most important products in pressure-sensitive adhesives (PSA).
The protective film is usually made of polyolefin plastic film as the base material and acrylic polymer as the base resin of the pressure-sensitive adhesive, which is processed by a coating machine.
The real meaning of the protective film is a temporary protective measure taken to prevent surface scratches during the storage, transportation and circulation of goods, or between the processing steps of the substrate.
The protective film is widely used in the surface protection of aluminum panels, aluminum-plastic composite panels, mirror effect steel plates, color panels, plexiglass panels, decorative panels, aluminum profiles, plastic steel profiles, stainless steel coils, marble materials and display screens.
The protective film for aluminum profile is based on a polyethylene (PE) film with a specific formula, polyacrylic acid (ester) resin is used as the main material of the pressure-sensitive adhesive, and several specific adhesives are coated, slit, and processed in packaging and other processes.
The protective film is soft in nature, good in adhesion, easy to stick, and easy to peel off.
The pressure-sensitive adhesive has good stability and will not have any adverse effects on the surface of aluminum profile to be filmed.
1. The structure and material characteristics of the protective film
The protective film is generally a polyacrylate type protective film.
The basic structure of the polyacrylate type protective film (Figure 1): from top to bottom: isolation layer; printing layer; film; adhesive layer.
1.1 Film
The film generally uses low-high-density polyethylene (PE) and polyvinyl chloride (PVC) as raw materials.
It can be obtained by extrusion molding, injection molding, and blow molding.
Because polyethylene is cheaper and more environmentally friendly, 90% of the film is made of polyethylene, mainly by blow molding.
There are many types of polyethylene, with different melting points and densities.
1.2 Adhesive
The key to the quality of the protective film is determined by the characteristics of the colloid.
There are two kinds of pressure-sensitive adhesives used in the protective film: solvent-based polyacrylate glue and water-soluble polyacrylate glue, which have different characteristics.
1.2.1 Solvent-based polyacrylate glue
Solvent-based polyacrylate glue uses organic solvents as a medium to dissolve acrylic monomers.
The colloid is very transparent, has a relatively low initial viscosity, and is very resistant to aging.
It can last up to 10 years, when exposed to ultraviolet rays, the colloid will slowly Curing.
After the film is corona treated, the polyacrylate glue can be directly coated without primer.
Polyacrylate glue is hard and has poor fluidity, so the adhesion of the protective film is slower.
Even after pressure, the glue and the surface to be attached cannot be fully contacted.
After being placed for 30 to 60 days, it will fully contact the surface to achieve final adhesion,
And the final viscosity is often 2 ~ 3 times larger than the viscosity of the paste,
If the viscosity of the protective film is suitable for the cutting, the end-user may be very laborious when tearing the film, or even cannot be torn off.
1.2.2 Water-soluble polyacrylate glue
Water-soluble polyacrylate glue uses water as a medium to dissolve acrylic monomers,
And basically has the characteristics of solvent-based polyacrylate glue,
But the glue should avoid and reduce contact with water and air to avoid residual glue.
Since water-soluble polyacrylate glue is more environmentally friendly and does not require a solvent recovery device, this glue is often used to produce protective films in developing countries.
1.3 Characteristics of adhesive
1.3.1 Adhesion
Refers to the force required to peel the protective film from the surface to be attached after a period of time.
Adhesion is related to the material to be attached, pressure, film application time, angle and temperature when tearing the film.
Generally, with the increase of time and pressure, the adhesion will also increase, and the viscosity of the protective film should not increase too much to ensure that there is no residual glue when the film is torn.
Generally, a 180-degree peeling test is used to measure adhesion.
1.3.2 Cohesion
Refers to the strength of the inside of the adhesive.
The cohesion of the colloid as a protective film must be very high,
Otherwise, when the protective film is torn apart, the inside of the colloid will crack and cause residual glue.
Cohesion measurement method: stick the protective film on the stainless steel surface, and hang a certain weight on the protective film to measure how long it takes for the protective film to be pulled off by the weight.
If the adhesion force is greater than the cohesion force, tear off the protective film, and the bond between the glue molecules will break and cause residual glue.
1.3.3 Bonding force
Refers to the binding force of adhesive and film.
If the adhesion force is greater than the adhesion force, tear off the protective film, and the bond between the glue molecule and the film will be broken, resulting in residual glue.
1.3.4 UV resistance
Polyacrylate glue is UV resistant. After the transparent polyacrylate glue protective film is added with a UV stabilizer, its UV resistance can reach 3 to 6 months.
Generally, climate simulation equipment is used to test the UV resistance of the protective film.
The temperature and radiation intensity is adjusted and the condensed water is used to imitate climate change.
Every 3 hours of high humidity environment and 7 hours of ultraviolet radiation is a cycle, and a 50-hour cycle experiment is equivalent to approximately leaving it outdoors for a month.
2. Production of protective film
2.1 Production of protective film
In the heated drum, the polyethylene particles are pushed by the screw to the round die head, and compressed air will blow the molten liquid, through the air cooling, rolled into a film.
The properties of the blown film in the transverse and longitudinal directions are different.
The elongation in the machine direction of the protective film is generally greater than 180%, and the elongation in the transverse direction is generally greater than 380%.
However, the elongation is inversely proportional to the mechanical strength.
If the elongation is too large (such as greater than 500%), the mechanical strength of the film will often be very low, which will easily cause the protective film to be damaged during transportation and handling,
And when unwinding, the protective film is easily stretched, after cutting, the protective film will rebound and warp.
2.2 Coating of adhesive
The corona-treated film can be directly coated with polyacrylate glue, no primer is required.
Then the protective film passes through a long air heating channel (80 ~ 120°C) to ensure that the water or solvent is evaporated, and then the protective film is cooled by a cooling roller, and finally rolled up.
2.3 Rewinding, slitting and storage
The protective film is directly rewound on the coating machine to the length required by the customer.
If the customer needs the protective film to have a beautiful appearance and no bubble wrap, it can be rewinded with a high-quality rewinder to ensure that there is no air wrap.
For short protective film (under 500 meters), a straight knife can be used for slitting. Over 500 meters, the heat generated when slitting with a straight knife may melt the polyethylene, making it difficult to unwind, or even tear the film.
The protective film can generally be stored for 12 months at a room temperature of 30°C and no direct sunlight.
The higher the temperature, the shorter the storage period. For every 10°C higher, the storage period will be reduced by half.
3. Application of protective film
Generally, there is a curved roll (Banana roll) on the aluminum profile film application machine to open the protective film to avoid bubbles and wrinkles.
For a low-viscosity protective film, the lower the tension when it is unwound, the better it will be, otherwise, the edges will be warped.
The filming temperature should be higher than 10°C, and the tearing temperature should also be higher than 10°C.
The peeling force is closely related to the speed and angle of the tearing film.
Too low a temperature will harden the protective film and warp the edges.
In this case, apply hot air to heat first, or produce in an air-conditioned workshop.
The hardness of the rubber pressure roller is generally 60A.
When the protective film is rewinding, more or less air is wrapped in the adhesive, causing the rubber surface to be slightly uneven.
If the rubber pressure roller is too soft, it will not be able to effectively drive out the air bubbles and flatten the adhesive.
If the rubber pressure roller is too hard, the pressure generated will not be enough to make the glue and aluminum profile effectively contact, and it is easy to cause the edge of the protective film when edge cutting.
Since the rubber pressure roller will gradually age and harden during use, the rubber roller should be checked and replaced frequently.
4 Application of protective film in aluminum industry
The protective film is a layer of plastic film sticking to the aluminum material.
The purpose is to protect the surface of the aluminum profile from damage during a series of processes such as handling, storage, transportation, processing, and installation.
After the aluminum profile is installed, the engineering team tore it off, so that the surface of the aluminum profile is as smooth as new, and it has the desired decorative effect.
There are many types of aluminum profiles on the market, and the surface treatment technology of aluminum materials is constantly improving.
Various aluminum surface treatment technologies include mechanical polishing, chemical polishing, anodizing, electrophoretic painting, chemical coloring, fluorocarbon spraying, electrostatic powder coating, wood grain effect sublimation treatment, etc.
Different aluminum profile surfaces need to be selected differently Adhesive protective film.
The protective film products generally have 4 series of low viscosity, medium viscosity, high viscosity and extra high viscosity; the colors are transparent, milky white, blue, black and white, etc.;
The thickness is 30 ~ 200μm, so it needs to be selected different protective films according to the different surfaces of the aluminum profile.
According to the different surfaces of aluminum profile and film pressure, the viscosity rise speed is different,
Generally, the protective film should be left for enough time before peeling off the protective film to determine whether the viscosity is appropriate.
For a given surface, it is extremely important to choose the appropriate adhesive and viscous protective film.
The further processing steps are the key to determining the viscosity. The subsequent processing generally includes cutting, bending, drilling, stamping, etc.
Generally, low-viscosity protective films are used for smooth surfaces, such as mechanical polishing and chemical polishing aluminum profiles.
Medium-viscosity protective films are used for medium-rough surfaces, such as anodizing, electrophoretic coating, chemical coloring, fluorocarbon spraying, and powder-coated aluminum profile.
Use high-viscosity protective film for very rough surfaces, such as electrostatic powder-coated aluminum profiles.
If laser cutting is required, because the protective film shrinks due to heat, you should use a super-high-viscosity protective film.
In addition to viscosity, users also need to test the tensile strength and elongation of the protective film to ensure that the flexibility and strength of the protective film can meet the requirements of the application.
5. Conclusion
During transportation, storage, processing, and assembly of aluminum materials, the surface of aluminum profile needs to be protected to prevent harmful gases, microbial corrosion, dust pollution, mechanical scratches, scratching, etc.,
So that the surface of the product retains the original high smoothness, improves the yield of secondary processing,
In addition, it can also be used for temporary protection in electroplating, printing, coating, printing and dyeing, etc.
The most commonly used method to protect the surface of the aluminum profile is to put a protective film on the surface of the material to be protected.
The value of the protective film in the aluminum industry is very small, which is only an auxiliary material used by the manufacturer.
However, if the protective film is used improperly or does not meet the requirements, the risk is that it will not only fail to protect but may damage it.
The surface quality of the product brings tangible material loss and intangible brand image loss to users, which ultimately affects the product manufacturer’s price position and product sales.
The correct application of the protective film not only improves the appearance quality of the aluminum profile, facilitates material processing, increases the utilization rate of the material, and reduces the production cost of the product, but also improves the brand image of the company.
On the necessity of aluminum profile automatic packaging
Reduce the labor cost and improve working efficiency
Aluminum profile automatic packaging importance
Aluminum profiles packaging situation
In recent years, the aluminum industry is facing many challenges such as economic contraction, labor shortage, anti-dumping policy and production cost increases.
Among them, the labor shortage seriously affects the overall development of the manufacturing industry.
In order to be able to cope with the impact of labor shortage, the aluminum processing industry is also actively exploring the use of automation and intelligent technology and equipment to increase profit, at the same time solve the problem of labor shortage, and improve the production efficiency and management capabilities of extruders.
It can be said that in the past few years, automated, intelligent and high-end manufacturing has become an important direction for the development of the aluminum industry.
It is the trend in the aluminum industry with automation and high technology equipment.
Aiming at changes in market demand and offering troubleshooting and solution for our customers, Brightstar Aluminum Machinery’s fully automatic packaging line can reduce the number of workers and increase production efficiency by 2-3 times, which is in line with current aluminum processing companies’ development needs for automated manufacturing production.
The pain point for aluminum extruders
The problem of aluminum profile packaging is a pain point for most aluminum extrusion profile manufacturers.
The weight of one bundle of aluminum profiles can reach about 10-50 kg.
This weight needs to be packaged by 2-3 people in the traditional manual packaging method.
Extrusion factories generally set up two-shift work, which is labor-intensive for the packaging workers.
It is difficult to guarantee work efficiency for 12 hours a day.
And a little carelessness can also cause packaging loss and uneven packaging quality.
What’s more, if the weight of aluminum profiles packed at one time is too heavy, it is easy to cause industrial accidents, which is really a big loss for the extruder.
There are too many drawbacks to the traditional manual packaging method for aluminum profiles.
In recent years, with the gradual disappearance of the demographic dividend period, the labor cost has continuously increased, the disadvantages have been highlighted, and the manpower problem has reached a point where it cannot be ignored.
If only 2-3 workers are required to complete this packaging work, it can be accepted by the extruders. But for the whole production line, the number of packaging workers required is far more than 2-3 workers.
For the entire packaging production line, aluminum profile bagging packaging is one kind of process, and after bagging is done, it must be loaded and sent to the hot shrink film packaging machine for the next process. This is another process.
The whole packaging process goes through and it will need at least 6 workers to complete the whole packaging.
Aluminum profile automatic packaging line necessity and importance
From the view of the entire packaging production line, we once again emphasized the importance and necessity of adopting the implementation of aluminum profile automatic packaging line.
In response to this problem, Brightstar Aluminum Machinery, which is as a specialist in one-stop aluminum packaging solutions, offers the optimal solution for our customers.
After many years of continuous testing and optimization, Brightstar Aluminum Machinery has now developed aluminum profile automatic packaging production line that can be customized for the extruders’ production workshop.
The entire production line is divided into eight module groups, including feeding, automatic conveying, automatic film cutting, automatic bagging, hot shrink packaging, automatic conveying and storage and automatic discharging process.
Benefits of automatic packaging line
The application of aluminum profile automatic packaging production line saves the cumbersome work such as intermediate loading, unloading and materials transportation in the workshop.
Only 1-3 workers can complete the entire packaging process, compared with the traditional manual packaging, the working efficiency Increase by 3-4 times, effectively reducing labor costs by 40%.
Automated packaging equipment replaces the traditional manual method, saving not only the extruders’ expenditure on workers’ salaries but also the extruders’ management costs.
It can be said that an automated packaging line improves the controllability of the production process, which is helpful for the extruders to collect production line data in time and in order to adjust more reasonable production planning and so on.
This is also the reason why Brightstar Aluminum Machinery believes that the future of automation replacing labor is the trend.
No matter which industry field requires automation equipment to solve the problem of labor costs, the market demand for automation machinery equipment can be described as increasing.
To achieve high-efficiency manufacturing, it is inseparable from the drive of high efficiency.
Brightstar understands the impact and value of automated and intelligent manufacturing for enterprise production.
Compared with the traditional manual packaging line, Brightstar Aluminum Machinery’s automatic packaging line can greatly reduce labor costs, reduce the scratch rate of aluminum profiles during transportation, improve product quality qualification rate, and thus improve overall production efficiency.
In addition, under the pressure of dealing with the current labor shortage, the automatic packaging production line can realize the transition from heavy manual labor to the operation of fully automated equipment, which will create a higher benefit space for aluminum industry.
Of course, in order to better serve aluminum profile packaging factories, Brightstar Aluminum Machinery has developed packaging automation equipment such as aluminum profile automatic film applicator machine, automatic bagging machine, aluminum profile wrapping machine and hot-shrink packaging machine based on the customers’ packaging needs.
