Aluminum alloy die casting

Japanese Industrial Standards JIS H 5302:2006

Japanese Industrial Standards JIS H 5302:2006

Aluminum alloy casting

The chart below is from the Japanese Industrial Standards and is based on the information contained in ISO/FDIS 3522Aluminium and aluminium alloys-Castings-Chemical composition and mechanical properties published in 2006.

Table 2 – Chemical Composition
Unit: Chemical composition (mass %)
Cu Si Mg Zn Fe Mn Cr Ni Sn Pb Ti Al
ADC1 1.0 max. 11.0 to 13.0 0.3 max. 0.5 max. 1.3 max. 0.3 max. 0.5 max. 0.1 max. 0.20 max. 0.30 max. Remainder
ADC3 0.6 max. 9.0 to 11.0 0.4 to 0.6 0.5 max. 1.3 max. 0.3 max. 0.5 max. 0.1 max. 0.15 max. 0.30 max. Remainder
ADC5 0.2 max. 0.3 max. 4.0 to 8.5 0.1 max. 1.8 max. 0.3 max. 0.1 max. 0.1 max. 0.10 max. 0.20 max. Remainder
ADC6 0.1 max. 1.0 max. 2.5 to 4.0 0.4 max. 0.8 max. 0.4 to 0.6 0.1 max. 0.1 max. 0.10 max. 0.20 max. Remainder
ADC10 2.0 to 4.0 7.5 to 9.5 0.3 max. 1.0 max. 1.3 max. 0.5 max. 0.5 max. 0.2 max. 0.2 max. 0.30 max. Remainder
ADC10Z 2.0 to 4.0 7.5 to 9.5 0.3 max. 3.0 max. 1.3 max. 0.5 max. 0.5 max. 0.2 max. 0.2 max. 0.30 max. Remainder
ADC12 1.5 to 3.5 9.6 to 12.0 0.3 max. 1.0 max. 1.3 max. 0.5 max. 0.5 max. 0.2 max. 0.2 max. 0.30 max. Remainder
ADC12Z 1.5 to 3.5 9.6 to 12.0 0.3 max. 3.0 max. 1.3 max. 0.5 max. 0.5 max. 0.2 max. 0.2 max. 0.30 max. Remainder
ADC14 4.0 to 5.0 16.0 to 18.0 0.45 to 0.65 1.5 max. 1.3 max. 0.5 max. 0.3 max. 0.3 max. 0.2 max. 0.30 max. Remainder
Al Si9(1) 0.10 max. 8.0 to 11.0 0.10 max. 0.15 max. 0.65 max. 0.50 max. 0.05 max. 0.05 max. 0.05 max. 0.15 max. Remainder
Al Si12(Fe)(2) 0.10 max. 10.5 to 13.5 0.10 max. 0.15 max. 1.0 max. 0.55 max. 0.15 max. Remainder
Al Si10Mg(Fe)(1) 0.10 max. 9.0 to 11.0 0.20 to 0.50 0.15 max. 1.0 max. 0.55 max. 0.15 max. 0.05 max. 0.15 max. 0.20 max. Remainder
Al Si8Cu3(2) 2.0 to 3.5 7.5 to 9.5 0.05 to 0.55 1.2 max. 0.8 max. 0.15 to 0.65 0.35 max. 0.15 max. 0.25 max. 0.25 max. Remainder
Al Si9Cu3(Fe)(2) 2.0 to 4.0 8.0 to 11.0 0.05 to 0.55 1.2 max. 1.3 max. 0.55 max. 0.15 max. 0.55 max. 0.25 max. 0.35 max. 0.25 max. Remainder
Al Si9Cu3(Fe)(Zn)(2) 2.0 to 4.0 8.0 to 11.0 0.05 to 0.55 3.0 max. 1.3 max. 0.55 max. 0.15 max. 0.55 max. 0.25 max. 0.35 max. 0.25 max. Remainder
Al Si11Cu2(Fe)(2) 1.5 to 2.5 10.0 to 12.0 0.30 max. 1.7 max. 1.1 max. 0.55 max. 0.15 max. 0.45 max. 0.25 max. 0.25 max. 0.25 max. Remainder
Al Si11Cu3(Fe) 1.5 to 3.5 9.6 to 12.0 0.35 max. 1.7 max. 1.3 max. 0.60 max. 0.45 max. 0.25 max. 0.25 max. 0.25 max. Remainder
Al Si12Cu1(Fe)(2) 0.7 to 1.2 10.5 to 13.5 0.35 max. 0.55 max. 1.3 max. 0.55 max. 0.10 max. 0.30 max. 0.10 max. 0.20 max. 0.20 max. Remainder
Al Si17Cu4Mg 4.0 to 5.0 16.0 to 18.0 0.45 to 0.65 1.5 max. 1.3 max. 0.50 max. 0.3 max. 0.3 max. Remainder
Al Mg9(1) 0.10 max. 2.5 max. 8.0 to 10.5 0.25 max. 1.0 max. 0.55 max. 0.10 max. 0.10 max. 0.10 max. 0.20 max. Remainder

Notes(1) Chemical components other than those given in the above table, including those shown in the table with “—” i.e., no specification values, shall be 0.05% max. for individual elements and 0.15% in total.

   (2) Chemical components other than those given in the above table, including those shown in the table with “—” i.e., no specification values, shall be 0.05% max. for individual elements and 0.25% in total.

Japanese Industrial Standards JIS H 5302 : 2006
