Casting aluminium chemical composition

October 14, 2019 Blog 0 Comment
Casting aluminium chemical composition

Casting aluminium chemical composition

Casting aluminium chemical composition

Chemical Composition ( Mass % )
Alloy Cu Si Mg Zn Fe Mn Cr Ni Sn Pb Ti Al
ADC1 1.0 max 11.0 to 13.0 0.3 max 0.5 max 1.3 max 0.3 max 　 0.5 max 0.1 max 0.20 max 0.30 max Balance
ADC3 0.6 MAX 9.0 to 11.0 0.4 to 0.6 0.5 max 1.3 max 0.3 max 　 0.5 max 0.1 max 0.15 max 0.30 max Balance
ADC5 0.2 max 0.3 max 4.0 to 8.5 0.1 max 1.8 max 0.3 max 　 0.1 max 0.1 max 0.1 max 0.20 max Balance
ADC6 0.1 max 1.0 max 2.5 to 4.0 0.4 max 0.8 max 0.4 to 0.6 　 0.1 max 0.1 max 0.1 max 0.20 max Balance
ADC10 2.0 to 4.0 7.5 to 9.5 0.3 max 1.0 max 1.3 max 0.5 max 　 0.5 max 0.2 max 0.20 max 0.30 max Balance
ADC10Z 2.0 to 4.0 7.5 to 9.5 0.3 max 3.0 max 1.3 max 0.5 max 　 0.5 max 0.2 max 0.20 max 0.30 max Balance
ADC12 1.5 to 3.5 9.6 to 12.0 0.3 max 1.0 max 1.3 max 0.5 max 　 0.5 max 0.2 max 0.20 max 0.30 max Balance
ADC12Z 1.5 to 3.5 9.6 to 12.0 0.3 max 3.0 max 1.3 max 0.5 max 　 0.5 max 0.2 max 0.20 max 0.30 max Balance
ADC14 4.0 to 5.0 16.0 to 18.0 0.45 to 0.65 1.5 max 1.3 max 0.5 max 　 0.3 max 0.3 max 0.20 max 0.30 max Balance
AC4B 2.0 to 4.0 7.0 to 10.0 0.5 max 1.0 max 0.8 max 0.5 max 0.20 max 0.35 max 0.10 max 0.20 max 0.20 max Balance
AC2B 2.0 to 4.0 5.0 to 7.0 0.5 max 1.0 max 0.8 max 0.5 max 0.20 max 0.35 max 0.10 max 0.20 max 0.20 max Balance
AlSi9Mg 0.03 max 9.0 to 10.0 0.30 to 0.45 0.07 max 0.15 max 0.10 max 　 　 　 　 0.15 max Balance
AlSi10Mg 0.08 max 9.0 to 11.0 0.25 to 0.45 0.10 max 0.45 max 0.45 max 　 0.05 max 0.05 max 0.05 max 0.15 max Balance
AlSi9Cu1Mg 0.8 to 1.3 8.3 to 9.7 0.30 to 0.65 0.80 max 0.7 max 0.15 to 0.55 　 0.20 max 0.10 max 0.10 max 0.10 to 0.18 Balance
AlSi9Cu3(Fe) 2.0 to 4.0 8.0 to 11.0 0.05 to 0.55 3.0 max 1.3 max 0.55 max 0.15 max 0.55 max 0.25 max 0.35 max 0.25 max Balance
AlSi12Cu1(Fe) 0.7 to 1.2 10.5 to 13.5 0.35 max 0.55 max 1.3 max 0.55 max 0.10 max 0.30 max 0.10 max 0.20 max 0.20 max Balance
　 　 　 　 　 　 　 　 　 　 　 　 　
