Aluminium dross processing system loading for Nigeria customer

Aluminium dross processing system loading for Nigeria customer

Aluminium dross processing system loading for Nigeria customer

Dated on 16th and 17th December 2022, aluminium dross processing system container loading was completed for Nigeria customer.

It took 2 days to finish the loading for all machines and spare parts and tools with 3 sets of 40HQ containers.

Well done, Brightstar team! Your great support is always appreciated, our GOD!

Aluminium dross processing system includes aluminium dross machine, dross cooling machine, ball mill and sieving machine, the total solution for aluminium dross recovery and recycling.

Aluminium dross processing system project

Aluminium dross machine extracts the most aluminium metal from the hot dross, then cool the hot dross to normal temperature in a short time, then grinds and crushes them with a ball mill, sieve the crushed aluminium dross in different grades for secondary recovery.

Aluminium dross cooling machine, ball mill and sieving machine is known as 3 in 1 aluminium dross processing system,

The 3 in 1 aluminium dross processing system is the matched cooling, grinding and screening equipment for the aluminium dross machine and rotary furnace.

The main function is to cool down the hot dross after aluminium dross processing or rotary furnace through water spraying and heat exchange.

The purpose of cooling and screening in grades can reduce the burning loss of aluminum during the aluminium dross cooling process, effectively improving the recovery rate of aluminium.

The dross cooling, ball mill and screening machine are divided into a cooling rotary drum and screening drum, each has an independent transmission system, the cooling drum rotation speed is 2 rpm, the screening drum speed is 0-25 rpm, there are 3 discharge ports for the dross, which are fine, medium and coarse dross.

The cooling method of aluminium dross cooling machine is circulating water spraying, and the equipment base is a circulating cooling water pool.

The cooling water is evenly covered with the cooling drum body through the water pump and the spraying water pipe, and the hot aluminium dross exchanges heat with the cooling water through the drum body.

The cooling water temperature should not exceed 40°C to ensure the cooling effect of the hot aluminium dross.

If the amount of hot aluminium dross to be treated is too large, external circulating water can also be considered.

The hot aluminium dross from aluminium dross machine will flow to aluminium dross cooling drum, which is connected together and is automatic operation.

If the hot aluminium dross is from the rotary furnace, which is poured into the dross hopper and sent to the charging port of the dross cooling drum with a forklift.

It is cooled rapidly by spraying the cooling water outside the cooling drum. After cooling, it goes into the ball milling area at the back end of the dross cooling drum.

Aluminium dross ball mill loading for Nigeria customer

Grind the coarse dross and block dross into fine pieces, grind the fine-grained aluminum beads flat, and then pass through the screening area to sieve out the 60-mesh fine dross (aluminum content < 3%), and then sort out the medium particles below φ12mm (aluminum content about 15-25%) and coarse particles above φ12mm (aluminum content about 10-15%),

If there is more iron in the aluminum dross, a magnetic separator can be installed at the coarse particle dross unloading port to sort out the iron scraps.

Aluminium dross sieving machine loading for Nigeria customer

The fine, medium and coarse aluminium dross screened out by 3 in 1 aluminium dross processing system can be processed according to the needs.

The fine aluminium dross does not contain high aluminum content and can be directly sold out.

The medium aluminium dross and the coarse aluminium dross after iron removal can be sent back into the rotary furnace or melting furnace, both as a cooling agent and secondary aluminium recovery, as there is aluminum metal in medium and coarse dross.

The supporting cycle operation with the rotary furnace can increase the recovery rate of aluminum dross, and the economic benefits and social benefits are very obvious.

Not only aluminium dross processing system, but also the baghouse dust collector system, the total solution and turnkey project for aluminium recovery project!
